MODEL
|
RS-590B
|
|
Sealing Type
|
High Speed Flow Sealing (Electrostatic Adherence Type）
|
|
Installed Power
|
Sealer: 220V/50-60Hz/1Phase Tunnel: 380V/50-60Hz/3Phase
|
|
Packing Capacity
|
150 Packs per Minute (Depends on Product Size)
|
|
Sealing Height
|
125MM
|
|
Packing Width
|
240MM
|
|
Packing Size
|
Width + Height ≤ 450MM
|
|
Film Type
|
Single Layer POF Film
|
|
Max Film Roll Size
|
590MM (Width) X 280MM (Outer Diameter)
|
|
Working Height
|
780-850 MM
|
|
Sealing Machine Dimensions
|
4930 X 1130 X 1500 MM
|
|
Conveyor
|
Chains with Rotating Silicon Coated Rods
|
|
Rated Power Consumption
|
Max. 16 KW
|
|
Working Height
|
780 - 850 MM
|
|
Machine Material
|
Carbon Steel
|
|
Tunnel Machine Dimensions
|
2400 X 600 X 1550 MM
|
|
Weight (Net/ Gross)
|
1600KGS/ 1680KGS (For Reference Only, Including Sealer and Tunnel)
|
